3M 5411-CI-T4 Molded Rubber 15 kV Inline Splicing Kit
$91.00/ea
Usually ships within 8 to 12 Days
EA
Adding...
Already a Customer? Log in to view your pricing
Manufacturer 3M
Mfg Catalog # 5411-CI-T4
Irby Part # 53686

Overview

3M™ 5411 Series Molded Rubber QS-II Splice Kit is an inline splice that is designed to use with JCN or CN cables. Kit has 1 splice with a CI-T4 connector.

3M™ 5411 Series Molded Rubber QS-II Splice Kit includes 1 splice body, 2 silicone grease and 1 instruction sheet. It is chemical-resistant, UV-resistant and water-resistant. The kit is rated for 15 kV voltage applications. IEEE Approved.

  • Specially designed to use with JCN or CN cables
  • Chemical-resistant, UV-resistant and water-resistant
  • 0.63 to 0.9-in O.D. insulation
  • Accommodates wire size of 4 to 2/0 AWG (stranded) and 2 to 1/0 AWG (solid)
  • Rated for 15 kV applications
  • IEEE Approved
  • Includes 1 splice body, 2 silicone grease and 1 instruction sheet
  • 1 kit/case

Specifications

  • 3M ID: 80610737944
  • Connector Included: CI-T4
  • Insulation O.D. Range: 0.637 - 0.900 Inch
  • Insulation Outside Diameter Range: 0.637 - 0.900 Inch
  • Number of Conductors: 1
  • Product Series: 5411, 5411A & 5412 Series
  • Product Technology: Molded Rubber
  • Product Type: Splice
  • RoHS 2011/65/EU Compliant: Undetermined
  • RoHS EU Comments: Contact 3M for information
  • Shielding Type: Concentric Neutral (CN), Jacketed Concentric Neutral (JCN)
  • Solid Conductor Sizes: 1 AWG, 1/0 AWG, 2 AWG
  • Splice Type: Inline
  • Trademark: 3M
  • Voltage: 15 kV

Legal Disclaimer

  • Manufacturing Origin: USA
  • The designation that a product is Manufactured in the USA means the product undergoes substantial transformation in one of our U.S. Manufacturing plants. Some products contain imported components.
  • Note: 3M products offered on a government contract that require country of origin representation must be certified by 3M Trade Compliance. Contact customer service at 800-245-3573 to request a certificate.

Overview

UPC 05400750754
GTiN 00054007507543
Number of Conductors 1
Cable Type Concentric Neutral (CN); Jacketed Concentric Neutral (JCN)
Family Brand Name 3M
Voltage 15,000 Volt
Splice Type Inline
Product Type Splice
