Usually ships within 8 to 12 Days
Already a Customer? Log in to view your pricing
Manufacturer Hubbell
Mfg Catalog # AA20045
Irby Part # 3378456


  • Standard Product


  • Country of Origin: CN
  • Current / Amperage Rating: 200 A
  • Each - Height: 7.800 in
  • Each - Length: 13.200 in
  • Each - Width: 9.300 in
  • Industry Standard(s): UL Listed
  • Performance: Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 3,000V AC;Electrical - Max Working Voltage - 600V AC RMS;Environmental - Flammability - UL94-5VA and V-0 classification;Environmental - Operating Temperatures - Max. Continuous: 75° C;Min. Continuous: -40° C w/o impact;Mechanical - Impact Resistance - In accordance with UL746C;Mechanical - Product Identification - Identification and ratings are a part of the external label and molded into the receptacle mount;Mechanical - Terminal Identification - Terminals identified in accordance with North American and International conventions
  • Application: Metallic
  • Environmental Conditions: Watertight
  • NEMA Rating: Non-NEMA
  • Phase: Three Phase
  • Special Features: Standard Product
  • Standard: UL Listed
  • Type: Four-Way Back Box
  • Wattage: 120000
  • Wire Size: #2 AWG to #4/0 AWG


  • EU RoHS Indicator: No


Product UPC 78358581007
GTiN 00783585810072
Length 13.2 Inch
Width 9.300 in
Size Standard Sized Product
Color Gray
Type Four-Way Back Box
Material Thermoplastic
Product Series Back Boxes And Adapters
Applications Metallic
Height 7.8 Inch
Wire Size 2-0000 AWG
Wattage 120000 Watt
Family Brand Name Hubbell Wiring Device Kellems
TC Connection Pressure Screw Terminals
Current 200 A
Number of Poles 3 Pole
Number of Wires 4
Sub Brand IEC 309 Pin and Sleeve Devices
Voltage 600 VAC
Standard UL
Construction Cast
Environmental Conditions Watertight
Country of Origin China
